氯化钠（NaCl）衬底
氯化钠（NaCl）是一种无色透明的立方晶系晶体。作为一种可溶于水且极易潮解的材料，它无法进行化学抛光处理。NaCl衬底常用于红外透射窗口和傅里叶变换红外光谱仪（FTIR），也是CO₂激光器应用中的可靠光学材料选择。
氯化钠衬底物理性能
| 性能 | 参数 |
|---|---|
| 材料 | NaCl |
| 生长方法 | 晶体生长法 |
| 晶体结构 | M3 |
| 晶格常数 (Å) | a = 5.642 |
| 熔点 | 801°C |
| 密度 (g/cm³) | 2.16 |
| 波长范围 | 0.25 – 22.0 µm |
| 折射率 | 1.54427 |
| 透过率 | 0.9 |
| Nf 值 | 0.0127 |
规格参数
可选尺寸：10×10 mm、20×20 mm、30×30 mm、直径 50 mm（可按需定制）
厚度：2.0 mm、3.0 mm、5.0 mm
晶向：<100>、<110>、<111>
表面粗糙度 (Ra)：< 20 nm
包装信息
苏州科跃生产的NaCl衬底在Class 1000级洁净室中加工，并采用Class 100洁净袋或晶圆盒封装，确保储存和运输过程中的纯净度与防潮性能。
